HTML5 video player is being more and more popular day by day. Though it can stream with a given public video file url, sometimes you will need to control the streaming from your server script to provide additional facility like authentication, resume support, sending in partial chunks etc. In a recent project, I have something similar, where a video was needed to be streamed through PHP to client browser’s HTML5 player. Here I will try to share my experience and code that will help you to implement PHP HTML5 video streaming easily and efficiently.
Checkout The PHP HTML5 Video Streaming Demo
The VideoStream class Code:
Following is the simple class, that includes all HTML5 streaming logic and is responsible for perform the main streaming action:
To use this class, you will have to write simple code like as below:
$stream = new VideoStream($filePath); $stream->start();
Understanding the class and HTML5 Streaming logic:
The class simply takes the path of the video file as constructor parameter. It can either give it a local path, or even an amazon s3 file location as well(explained later).
after calling the ‘start()’ method, it first tries to open the file, then set the proper headers, then stream required contents and finally close the file system handler.
The header part is the most important as here you will be communicating with client browser, tell it that you can accept range request and check if browser made range requests or not and decide the amount of data to stream. In header setting, by default mp4 file’s mime type are given. You can change it according to your need. However, at this moment, mp4 is the most widely supported format across major browsers, so using this format is very much recommended. ‘Accept-Ranges’ header is important to tell the browser that server is accepting any byte level request in the given range, so that browser can decide range itself make custom range requests subsequently. When browser makes range request, it includes and additional header named ‘HTTP_RANGE’. Inside ‘setHeader()’ method, it just validates the range requests and decide how much data to send accordingly.
The ‘stream()’ method simply stream the predefined amount of data with a customizable buffer size.The buffer size is just to optimize the server memory utilization so that not huge memory is taken in case of concurrent high number of requests.
Streaming From Amazon S3 Service:
You can have s3 service’s file location support on the above class very easily. First, make sure to register ‘streamWrapper’ with your s3 client:
$s3Client->registerStreamWrapper();
then, while passing file path to VideoStream class’s constructor, use “s3://{bucket}/{key}” format as file string. Then modify the class’s ‘open()’ method, as below:
/**
* Open stream
*/
private function open()
{
// Create a stream context to allow seeking
$context = stream_context_create(array(
's3' => array(
'seekable' => true
)
));
if (!($this->stream = fopen($this->path, 'rb', false, $context))) {
die('Could not open stream for reading');
}
}
Now you should be fine and streaming should work from Amazon S3 location as well.
Final Words:
Hope this small tutorial on PHP HTML5 Video Streaming will help you to get started with your next video streaming app. If you have any suggestions to improve the class, please suggest through commenting. If you are having any trouble in understanding any of the parts, feel free to ask as well. Happy coding 🙂
